Xtar SC2 – Quick charger for Li-Ion batteries with QC 3.0 input

Fast-charging (2x 2A or 1x 3A) and two-bay charger designed for protected 20700/21700 batteries with *Quick Charge 3.0 input.
Light weight, fast charging capability, flexibility and size are the benefits of this charger.

Xtar complements with the SC2 charger the SC series with a two bays fast charger for batteries up to 76 mm, thus also the new battery size 20700/21700 was considered in the PCB protected version.

16650 / 18650 / 18700 / 20700 / 21700 / 22650 /25500 / 26650
Also for protected 20700 / 21700 with overlength up to 75,5mm suitable />3,6V and 3,7V Li-Ion batteries

Reverse polarity protection / short circuit protection / overcharge protection / overheat protection.

1x 3A or 2x 2A charging current with QC 3.0 USB adapter (depending on internal resistance of batteries)

1x 2A or 2x 1A charging current with a 5V 2.1A UCB adapter (depending on the internal resistance of the batteries)

QC 3.0 Micro-USB charging port

Compatible with 5V USB power supplies, including USB wall adapters, solar panels, power banks, etc.

0V battery activation

IC temperature monitoring system

Real-time LED indication of charging status

Real-time battery monitoring system

Voltage-dependent activation and deactivation of the charging process.

www.Lygte-Info.de

1. charge only 3.7V or 3.6V Li-ion batteries!
2. device is for home use, keep water and moisture away!
3. disassembly and modification are strictly prohibited!
4. please avoid short circuit.

Xtar SC2 charger, USB cable, instructions in German and other languages, (QC3.0 power supply optionally available Item: 400617, 400622)

*Quick Charge is the name for an originally manufacturer-specific transmission method of electrical power on the USB interface by communication with the charger and voltage sensing.

Technical Data

Note:

The above parameters are laboratory tested. Approximate values may vary between charger, batteries and environment.
